Leader Forged Steel Flanged Gate Valve (Class 150, 300, 600)

The Leader Forged Steel Gate Valve (Item Codes: FCS040 for Class 150, FCS043 for Class 300, and FCS001 for Class 600) is built for demanding high-pressure and high-temperature service. Manufactured in compliance with API 602, BSEN ISO 15761, and ASME B16.34 standards and tested to API 598 and BSEN 12266 Part-1, this valve features a solid wedge, renewable seats, outside screw and yoke (OS&Y), a rising stem, and a non-rising handwheel.

Technical Specifications

Parameter	Class 150 Specification	Class 300 Specification	Class 600 Specification
Item Code	FCS040	FCS043	FCS001
Size Range	15 mm to 50 mm	15 mm to 50 mm	15 mm to 50 mm
Max Working Pressure	20 Bar	52 Bar	103 Bar
Max Working Temp	425°C	425°C	425°C
Hydrostatic Body Test	30 Bar	77 Bar	154 Bar
Hydrostatic Seat Test	22 Bar	57 Bar	113 Bar
Air Seat Test	6.9 Bar	6.9 Bar	6.9 Bar
End Connection	ASME B16.5 RF	ASME B16.5 RF	ASME B16.5 RF
Media Compatibility	Water, Oil, Air, Gases, Steam	Water, Oil, Air, Gases, Steam	Water, Oil, Air, Gases, Steam

Key Features & Design Highlights

High-Integrity Sealing: Bolted body-bonnet joint equipped with a spiral-wound stainless steel gasket with graphite filler. Welded bonnet option available upon request.
Low Emissions & Safety: Features die-formed graphite inner packing rings with braided graphite end rings reinforced with Inconel wire and corrosion inhibitor. Qualified for API 624 / ISO 15848-1 low emission requirements and API 607 fire-safe performance.
API Compliant T-Head Stem-Disc Connection: Fully meets strength criteria of API 602 and API 598. Tapered stem shoulder provides positive back seating.
Self-Aligning Two-Piece Gland Flange: Allows uneven gland nut tightening without distorting or misaligning the parallel fit of the gland in the stuffing box.
High-Melting Point Yoke Sleeve: Constructed from forged stainless steel for superior wear and corrosion resistance.
Specialized Certifications: Available with IBR certification, NACE MR-0175 compliance, low-temperature carbon steel / austenitic SS forging for cryogenic service (BS 6364 qualification), or electrical actuators.

Material Specifications

Part No.	Part Name	Carbon Steel	Alloy Steel Options	Stainless Steel Options
1	Body	A105 / A350 LF2	A182 F5 / F11 / F22 / F9	A182 F304 / F316 / F304L / F316L
2	Seat Ring	ASTM A276 Type 410 / SS 304	SS 410	SS 304 / SS 316 / SS 304L / SS 316L
3	Wedge	ASTM A217 Gr. CA15 / ASTM A276 Type 410 / SS 304	CA15 / SS 410	SS 304 / SS 316 / SS 304L / SS 316L
4	Gasket	Spiral Wound Stainless Steel Graphoil Filler	Spiral Wound Stainless Steel Graphoil Filler	Spiral Wound Stainless Steel Graphoil Filler
5	Bonnet	A105 / A350 LF2	A182 F5 / F11 / F22 / F9	A182 F304 / F316 / F304L / F316L
6	Studs	A193 B7 / A320 L7	A193 B7 / A193 B16	A193 B8
7	Packing	Flexible Graphite	Flexible Graphite	Flexible Graphite
8	Gland	A182 F6a / SS 304	A182 F6a	SS 304 / SS 316 / SS 304L / SS 316L
9	Gland Flange	A105 / A350 LF2	A182 F5 / F11 / F22 / F9	A182 F304 / F316 / F304L / F316L
10	Nuts	A194 2H / A194 Gr. 4	A194 2H / A194 Gr. 4	A194 Gr. 8
11	Stem	ASTM A276 Type 410 / SS 304	SS 410	SS 304 / SS 316 / SS 304L / SS 316L
12	Yoke Sleeve	ASTM A582 Type 416	ASTM A582 Type 416	ASTM A582 Type 416
13	Hand Wheel	DI. A536 Gr. 80-55-06	DI. A536 Gr. 80-55-06	DI. A536 Gr. 80-55-06
14	Name Plate	Aluminium / Steel	Aluminium / Steel	Aluminium / Steel
15	HW Retaining Nut	Steel	Steel	Steel

Dimensional Data

Class 150 (Item Code: FCS040)

Size (mm)	L	~H	Øb	~ØHW	ØD	T	ØR	f	K	n	Ød
15	108	128	9.5	83	89	7.9	35.1	1.5	60.5	4	15.8
20	117	150	12.5	90	99	8.6	42.9	1.5	69.8	4	15.8
25	127	165	18	96	108	9.7	50.8	1.5	79.2	4	15.8
32	140	181	24	114	117	11.2	63.5	1.5	88.9	4	15.8
40	165	222	31	125	127	12.7	73	1.5	98.6	4	15.8
50	178	251	38	125	152	14.2	91.9	1.5	120.6	4	19.1

Class 300 (Item Code: FCS043)

Size (mm)	L	~H	Øb	~ØHW	ØD	T	ØR	f	K	n	Ød
15	140	128	9.5	83	95	12.7	35.1	1.5	66.5	4	15.8
20	152	150	12.5	90	117	14.2	42.9	1.5	82.6	4	19.1
25	165	165	18	96	124	15.7	50.8	1.5	88.9	4	19.1
32	178	175	24	103	133	17.5	63.5	1.5	98.6	4	19.1
40	190	222	31	125	155	19	73	1.5	114.3	4	22.3
50	216	235	38	135	165	20.6	91.9	1.5	127	8	19.1

Class 600 (Item Code: FCS001)

Size (mm)	L	~H	Øb	~ØHW	ØD	T	ØR	f	K	n	Ød
15	165	145	12.5	90	95	14.2	35.1	6.4	66.5	4	15.7
20	190	170	18	95	117	15.7	42.9	6.4	82.6	4	19.1
25	216	192	24	108	124	17.5	50.8	6.4	88.9	4	19.1
32	229	220	31	125	133	20.6	63.5	6.4	98.6	4	19.1
40	241	220	33	125	155	22.4	73	6.4	114.3	4	22.3
50	292	252	35	125	165	25.4	91.9	6.4	127	8	19.1

Dimensions legend: L = Face to Face, ~H = Height (Open), Øb = Bore Diameter, ~ØHW = Handwheel Diameter, ØD = Flange Outer Diameter, T = Flange Thickness, ØR = Raised Face Diameter, f = Raised Face Height, K = PCD, n = Number of Holes, Ød = Hole Diameter.
