Leader Forged Steel Globe Valve Class-600 (Flanged)

The Leader Forged Steel Globe Valve (Item Codes: FCS038 for Class 150, FCS041 for Class 300, and FCS006 for Class 600) is built for shut-off and throttling services in high-pressure and high-temperature pipelines. Standardized under BS 5352 and BSEN ISO 15761, it operates without relative friction between the disc and body seating surfaces to maximize service life.

Technical Specifications

Parameter	Class 150 Specification	Class 300 Specification	Class 600 Specification
Item Code	FCS038	FCS041	FCS006
Size Range	15 mm to 50 mm	15 mm to 50 mm	15 mm to 50 mm
Max Working Pressure	20 Bar	52 Bar	103 Bar
Max Working Temp	425°C	425°C	425°C
Hydrostatic Body Test	30 Bar	77 Bar	154 Bar
Hydrostatic Seat Test	22 Bar	57 Bar	113 Bar
Air Seat Test	6.9 Bar	6.9 Bar	6.9 Bar
End Connections	ASME B16.5 RF	ASME B16.5 RF	ASME B16.5 RF
Suitable Media	Water, Oil, Air, Gases, Steam	Water, Oil, Air, Gases, Steam	Water, Oil, Air, Gases, Steam

Key Features & Design Highlights

Renewable Seating & Zero Friction: Comes standard with renewable seats. Zero relative friction between the disc and body sealing face during rotation ensures low wear and tight shut-off.
Bolted Bonnet Joint Security: Bolted body-bonnet connection utilizes a spiral-wound stainless steel gasket filled with graphite. Welded bonnets are available on request.
Low Emissions & Fire Safety: Features die-formed graphite inner packing rings with Inconel wire-reinforced braided graphite end rings. Qualified to API 624 / ISO 15848-1 FET and API 607 (Fire Safe) standards.
Self-Aligning Two-Piece Gland: The gland and gland flange assembly maintains parallel stem alignment inside the stuffing box even during uneven bolt tightening.
Back Seating & High-Temp Materials: Tapered stem shoulder provides back seating capabilities. Yoke sleeve is forged stainless steel for high melting point and wear resistance.
Specialized Options: Available with IBR certification, NACE MR-0175 compliance, electrical actuators, or BS 6364 cryogenic qualifications (extended bonnet).

Material Specifications

Part No.	Part Name	Carbon Steel	Alloy Steel Options	Stainless Steel Options
1	Body	A105 / A350 LF2	A182 F5 / F11 / F22 / F9	A182 F304 / F316 / F304L / F316L
2	Seat Ring	ASTM A276 Type 410 / SS 304	SS 410	SS 304 / SS 316 / SS 304L / SS 316L
3	Disc	ASTM A217 Gr. CA15 / ASTM A276 Type 410 / SS 304	CA15 / SS 410	SS 304 / SS 316 / SS 304L / SS 316L
4	Gasket	Spiral Wound SS Graphoil Filler	Spiral Wound SS Graphoil Filler	Spiral Wound SS Graphoil Filler
5	Bonnet	A105 / A350 LF2	A182 F5 / F11 / F22 / F9	A182 F304 / F316 / F304L / F316L
6	Studs	A193 B7 / A320 L7	A193 B7 / A193 B16	A193 B8
7	Packing	Flexible Graphite	Flexible Graphite	Flexible Graphite
8	Gland	A182 F6a / SS 304	A182 F6a	SS 304 / SS 316 / SS 304L / SS 316L
9	Gland Flange	A105 / A350 LF2	A182 F5 / F11 / F22 / F9	A182 F304 / F316 / F304L / F316L
10	Nuts	A194 2H / A194 Gr. 4	A194 2H / A194 Gr. 4	A194 Gr. 8
11	Stem	ASTM A276 Type 410 / SS 304	SS 410	SS 304 / SS 316 / SS 304L / SS 316L
12	Yoke Sleeve	ASTM A582 Type 416	ASTM A582 Type 416	ASTM A582 Type 416
13	Hand Wheel	DI. A536 Gr. 80-55-06	DI. A536 Gr. 80-55-06	DI. A536 Gr. 80-55-06
14	Name Plate	Aluminium / Steel	Aluminium / Steel	Aluminium / Steel
15	HW Retaining Nut	Steel	Steel	Steel

Dimensional Data

Class 150 (Item Code: FCS038)

Size (mm)	L	~H	Øb	~ØHW	ØD	T	Ødk	f	K	n	Ød
15	108	140	9.5	82	89	7.9	34.9	1.5	60.5	4	15.8
20	117	155	12.7	90	99	8.6	42.9	1.5	69.8	4	15.8
25	127	175	18	96	108	9.7	50.8	1.5	79.2	4	15.8
32	140	198	23	114	117	11.2	63.5	1.5	88.9	4	15.8
40	165	240	30	155	127	12.7	73	1.5	98.6	4	15.8
50	203	270	37	155	152	14.2	92.1	1.5	120.6	4	19

Class 300 (Item Code: FCS041)

Size (mm)	L	~H	Øb	~ØHW	ØD	T	Ødk	f	K	n	Ød
15	152	155	9.5	90	95	12.7	34.9	1.5	66.5	4	15.8
20	178	155	12.7	90	117	14.2	42.9	1.5	82.6	4	19.1
25	203	198	17.5	114	124	15.7	50.8	1.5	88.9	4	19.1
32	216	242	23	114	133	17.5	63.5	1.5	98.6	4	19.1
40	229	242	30	155	155	19	73	1.5	114.3	4	22.3
50	267	270	36	155	165	20.6	92.1	1.5	127	8	19.1

Class 600 (Item Code: FCS006)

Size (mm)	L	~H	Øb	~ØHW	ØD	T	Ødk	f	K	n	Ød
15	165	155	12.7	90	95	14.2	35.1	6.4	66.5	4	15.7
20	190	172	18	96	117	15.8	42.9	6.4	82.5	4	19.1
25	216	210	23	114	124	17.5	50.8	6.4	88.9	4	19.1
32	229	235	30	155	133	20.6	63.5	6.4	98.6	4	19.1
40	241	235	30	155	155	22.4	73	6.4	114.3	4	22.3
50	292	270	36	155	165	25.4	91.9	6.4	127	8	19.1

Dimensions legend: L = Face to Face, ~H = Open Height, Øb = Bore Diameter, ~ØHW = Handwheel Diameter, ØD = Flange Outer Diameter, T = Flange Thickness, Ødk = Raised Face Diameter, f = Raised Face Height, K = PCD, n = Number of Holes, Ød = Hole Diameter.
