Leader Forged Brass Gate Valve 2 MPa (IS 026)

The Leader Forged Brass Gate Valve (2 MPa) provides bi-directional flow isolation in compact industrial and residential piping systems. Manufactured according to IS 13114 standards, this heavy-duty, full-bore gate valve features a non-rising stem setup and deep-cut internal threads for maximum durability under pressure.

Key Product Features

• Full-Bore Flow Design: Features an unobstructed, full-bore internal pathway that minimizes pressure loss across the line.
• Pressure Re-packing System: Engineered with a back-seating facility that allows safe gland re-packing while the system is fully pressurized.
• High-Tensile Brass Stem: Constructed with robust forged brass stems to resist torque shearing during manual actuation.
• Clear Position Identification: Includes visual open/close position markings on the handwheel nameplate for easy operation.
• Standard Parallel Threading: Screwed female parallel pipe threads designed in accordance with IS 554 specifications.
• Screwed-In Bonnet: Built with an inside screw, non-rising stem, and integral seating surfaces for compact vertical footprint clearance.

Operating Limits & Specifications

• Product & Testing Standard: IS 13114 (CM/L-9178290)
• Item Code: IS 026
• Nominal Pressure Rating: 2 MPa
• Hydrostatic Shell Test Pressure: 3.0 MPa (435 psig)
• Hydrostatic Seat Test Pressure: 2.2 MPa (319 psig)
• Temperature Limits: Up to 180°C (10 Bar rating drop) | 45°C standard working rating
• Media Compatibility: Potable water, treated fresh water, neutral liquids, air, and non-corrosive gases.

Materials of Construction (MOC)

Dimensions & Sizing Reference
