ZOLOTO 1003 BRONZE GLOBE VALVE NO. 8 (FLANGED)

Zoloto 1003 Bronze Globe Valve No. 8 (Flanged)

Introduction

The Zoloto 1003 Bronze Globe Valve No. 8 (Flanged) is a medium-pattern, flanged flow-control valve designed for commercial, industrial, and utility piping systems requiring secure, bolted flange connections. Manufactured by Zoloto Industries, this valve delivers linear throttling and leak-tight shut-off performance for media including water, oil, air, and gases. Its flanged design simplifies installation and dismantling in pipelines where threaded connections are impractical or restricted by engineering specifications.

Product Overview

Model 1003 is constructed with an inside-screw, rising stem mechanism, a screwed-in bonnet, and an integral valve seat. The primary body and internal components—including the body, bonnet, disc, and disc nut—are cast from corrosion-resistant Leaded Tin Bronze (IS 318 Gr. LTB2). The valve stem, gland, and gland nut are made from high-strength Forged Brass (IS 6912 Gr. FLB).

To ensure joint integrity between pipe flanges, the end connections conform to the BS 10 Table 'D' flanged standard. The valve features premium-quality pure PTFE gland packing, providing reliable stem sealing across operating temperatures up to 225°C . For specialized compressed air or gas installations, a soft PTFE seating variant is available. Additionally, the manufacturer offers optional open-shut position indicators and locking devices upon request.

Technical Specifications

Key Features

• Flanged Ends Standard: Flanged end connections conforming to BS 10 Table 'D' ensure stable mounting and easier removal during plant maintenance.
• Corrosion-Resistant Cast Bronze: Body, bonnet, disc, and disc nut manufactured from IS 318 Gr. LTB2 bronze resist aqueous corrosion and erosion.
• Rising Stem Operation: Inside screw rising stem design provides quick visual indication of valve open/closed status.
• PTFE Stem Seal: High-grade PTFE gland packing offers thermal stability and zero-leakage stem performance up to 225°C.
• Ergonomic Handwheel: Designed powder-coated sheet metal handwheel enables convenient manual operation and positive closing torque.

Working Principle / Operating Mechanism

The Zoloto 1003 flanged valve functions through the manual rotation of its handwheel, which turns the forged brass stem. Rotating the handwheel counterclockwise raises the stem and bronze disc off the integral seat, establishing an unobstructed flow channel through the body. Turning the handwheel clockwise lowers the disc firmly onto the seat to cut off fluid flow. The vertical linear stem movement allows fine-tuned manual throttling of the fluid media.

Industrial Applications

• Industrial Utility Pipelines: Water supply lines and auxiliary utility loops in processing plants requiring flanged joints.
• Steam & Thermal Lines: Low-to-medium pressure steam networks operating within the 225°C temperature rating.
• Compressed Air Distribution: Air handling headers where flanged valve connections are specified (PTFE soft seat recommended).
• Fuel & Oil Handling: Fuel oil transfer systems and lubrication oil circulation lines.

Benefits

• Convenient Pipeline Maintenance: Flanged connection to BS 10 Table 'D' allows simple insertion and removal without cutting pipe runs.
• Accurate Flow Throttling: Globe valve flow geometry allows effective regulation of line flow rates compared to standard gate valves.
• High Hydrostatic Rating: Shell tested up to 24kg/cm2g and seat tested up to 16kg/cm2g for process stability.

Zoloto Valve Dealer in Ahmedabad and Gujarat

Engineers, plant maintenance managers, and contractors in major Gujarat industrial hubs—including Ahmedabad, Vadodara, Surat, Rajkot, and Gandhinagar—frequently require flanged bronze valves for utility networks. Sourcing through a reputable Zoloto valve supplier in Gujarat helps ensure project compliance, verified test pressure parameters, and genuine material grades.

Why Choose Awal Valve

Awal Valve supports industrial procurement teams, maintenance personnel, and project engineers in sourcing piping valves across diverse applications.

• Broad Product Range: Supply capabilities covering bronze, brass, cast iron, and forged steel valves across multiple pressure classes.
• Technical Support: Guidance in selecting suitable valve models based on media, temperature, pressure class, and flange standards.
• Prompt Quotes: Rapid response times for commercial pricing and technical documentation requirements.

Note: Product availability, pricing, lead times, and official authorization status should be confirmed directly with Awal Valve during enquiry.

Conclusion

The Zoloto 1003 Bronze Globe Valve No. 8 (Flanged) offers a dependable flanged flow control solution for water, oil, air, and gas utilities. Featuring IS 318 Gr. LTB2 bronze body construction, BS 10 Table 'D' flanges, and a 225°C maximum temperature limit, it fulfills standard industrial specifications. Contact Awal Valve to submit enquiries, request pricing, or verify technical parameters.

Frequently Asked Questions (FAQs)

Q1. What is the Zoloto 1003 Bronze Globe Valve No. 8?

The Zoloto 1003 is a medium-pattern bronze globe valve equipped with BS 10 Table 'D' flanged ends, an inside screw rising stem, integral seat, and PTFE gland packing. It regulates or isolates water, oil, air, and gas flow in flanged piping systems.

Q2. What are the technical specifications of the Zoloto 1003?

Verified specifications include an IS 318 Gr. LTB2 Bronze body/bonnet, BS 10 Table 'D' flanged connections, shell test pressure of 24kg/cm2g, seat test pressure of 16kg/cm2g, maximum temperature of 225°C, and sizes ranging from 1/2" to 2".

Q3. What flange standard does the Zoloto 1003 conform to?

The end flanges are machined to conform to BS 10 Table 'D' dimensions.

Q4. How can I enquire about the Zoloto 1003 through Awal Valve?

You can submit a purchase or technical enquiry directly through the Awal Valve website or reach out to their sales team via phone or email.

Q5. How can I confirm availability, pricing, and technical suitability?

Contact Awal Valve directly with your application parameters (operating pressure, temperature, fluid media, size, and flange requirements) to confirm stock levels, request commercial pricing, and verify technical fit.
