Bronze Auxiliary Steam Stop Valve Straight Pattern (Flanged)

Salient Features:-

Flanged Ends to BS 10 Table ‘H’.
Straight Pattern, Screwed / Bolted Bonnet, Outside Screw, Rising Stem, Yoke Type.
Provision for re-packing under pressure.
Handwheel Operated.
Premium Quality lubricated Gland Packing.
Renewable 13% Cr. Stainless Steel (SS 410) working parts.
Heat treated body seat ring and disc for extended life.

Test Pressure (Hydrostatic) :

Shell : 35.15 kg/cm²g (500 psig)
Working Pressure (Steam) : 17.58 kg/cm²g (250 psig)
Maximum Working Temperature : 225°C

Suitable For :

Steam, Water
