Leader Forged Steel Globe Valve (Socket Weld / Screwed)

The Leader Forged Steel Globe Valve (Class 800 & Class 1500) (Item Codes: FCS007 for Class 800 Reduced Bore, FCS008 for Class 800 Full Bore, and FCS009 for Class 1500) is designed for reliable flow throttling and shut-off in extreme temperature and high-pressure piping systems. Engineered per BSEN ISO 15761 and ASME B16.34, it utilizes an Outside Screw and Yoke (OS&Y) design with a rising stem and non-rising handwheel.

Technical Specifications

Parameter	Class 800 Specification	Class 1500 Specification
Item Codes	FCS007 (Reduced Bore) / FCS008 (Full Bore)	FCS009
Size Range	15 mm to 50 mm	15 mm to 50 mm
Max Working Pressure	138 Bar	255 Bar
Max Working Temp	425°C	425°C
Hydrostatic Body Test	207 Bar	384 Bar
Hydrostatic Seat Test	152 Bar	281 Bar
Air Seat Test	6.9 Bar	6.9 Bar
Design Standards	BSEN ISO 15761, ASME B16.34	BSEN ISO 15761, ASME B16.34
Testing Standards	API 598, BSEN 12266 Part-1	API 598, BSEN 12266 Part-1
End Connections	Socket Weld (ASME B16.11), Screwed Female NPT/BSP, Butt Weld	Socket Weld (ASME B16.11), Screwed Female NPT/BSP, Butt Weld
Suitable Media	Water, Oil, Air, Gases, Steam	Water, Oil, Air, Gases, Steam

Key Features & Design Highlights

Zero Seating Friction: Eliminates relative friction between the disc and body seating surface during operation to extend valve service life.
Bolted/Welded Bonnet Joint: Features a bolted body-bonnet joint with a spiral-wound stainless steel gasket and graphite filler for leak prevention. Welded bonnets are optional.
Low Emissions & Fire Safety: Die-formed graphite inner packing with Inconel wire-reinforced braided end rings and corrosion inhibitor. Qualified to API 624 / ISO 15848-1 FET and API 607 Fire Safe standards.
Self-Aligning Gland Flange: Two-piece gland flange assembly prevents stem binding by maintaining parallel alignment even under uneven bolt tightening.
Back Seating & High-Temp Sleeve: Tapered shoulder on the stem enables effective back seating under pressure. Yoke sleeve is forged stainless steel with a high melting point for wear and corrosion resistance.
Optional Configurations: Available with IBR certification, NACE MR-0175 compliance, electrical actuators, or BS 6364 cryogenic qualifications (extended bonnet).

Material Specifications

Part No.	Part Name	Carbon Steel	Alloy Steel Options	Stainless Steel Options
1	Body	A105 / A350 LF2	A182 F5 / F11 / F22 / F9	A182 F304 / F316 / F304L / F316L
2	Seat Ring	ASTM A276 Type 410 / SS 304	SS 410	SS 304 / SS 316 / SS 304L / SS 316L
3	Disc	ASTM A217 Gr. CA15 / ASTM A276 Type 410 / SS 304	CA15 / SS 410	SS 304 / SS 316 / SS 304L / SS 316L
4	Gasket	Spiral Wound SS Graphoil Filler	Spiral Wound SS Graphoil Filler	Spiral Wound SS Graphoil Filler
5	Bonnet	A105 / A350 LF2	A182 F5 / F11 / F22 / F9	A182 F304 / F316 / F304L / F316L
6	Studs	A193 B7 / A320 L7	A193 B7 / A193 B16	A193 B8
7	Packing	Flexible Graphite	Flexible Graphite	Flexible Graphite
8	Gland	A182 F6a / SS 304	A182 F6a	SS 304 / SS 316 / SS 304L / SS 316L
9	Gland Flange	A105 / A350 LF2	A182 F5 / F11 / F22 / F9	A182 F304 / F316 / F304L / F316L
10	Nuts	A194 2H / A194 Gr. 4	A194 2H / A194 Gr. 4	A194 Gr. 8
11	Stem	ASTM A276 Type 410 / SS 304	SS 410	SS 304 / SS 316 / SS 304L / SS 316L
12	Yoke Sleeve	ASTM A582 Type 416	ASTM A582 Type 416	ASTM A582 Type 416
13	Hand Wheel	DI. A536 Gr. 80-55-06	DI. A536 Gr. 80-55-06	DI. A536 Gr. 80-55-06
14	Name Plate	Aluminium / Steel	Aluminium / Steel	Aluminium / Steel
15	HW Retaining Nut	Steel	Steel	Steel

Dimensional Data

Class 800 - Reduced Bore (Item Code: FCS007)

Size (mm)	L	Øb	~ØHW	~H	C	Rc	ØSW	D
15	80	10	82	140	17	1/2"	22.2 / 21.8	11
20	88	12.7	90	155	18	3/4"	27.6 / 27.2	14
25	100	18	96	175	21	1"	34.3 / 33.9	14
32	124	23	114	198	21	1-1/4"	43.1 / 42.7	14
40	145	30	155	240	23	1-1/2"	49.2 / 48.8	14
50	170	35	155	270	24	2"	61.7 / 61.2	17

Class 800 - Full Bore (Item Code: FCS008)

Size (mm)	L	Øb	~ØHW	~H	C	Rc	ØSW	D
15	100	12	96	172	17	1/2"	22.2 / 21.8	11
20	124	16	114	201	18	3/4"	27.6 / 27.2	14
25	145	19	155	235	23	1"	34.3 / 33.9	14
32	170	27	155	270	24	1-1/4"	43.1 / 42.7	14
40	170	32	155	270	24	1-1/2"	49.2 / 48.8	14

Class 1500 (Item Code: FCS009)

Size (mm)	L	Øb	~ØHW	~H	C	Rc	ØSW	D
15	88	12.7	90	155	18	1/2"	22.2 / 21.8	14
20	100	18	96	175	21	3/4"	27.6 / 27.2	14
25	124	23	114	198	21	1"	34.3 / 33.9	14
32	145	30	155	240	23	1-1/4"	43.1 / 42.7	14
40	170	35	155	270	24	1-1/2"	49.2 / 48.8	14
50	228	47.5	155	334	24	2"	61.7 / 61.2	17

Dimensions legend: L = End-to-End Length, Øb = Bore Diameter, ~ØHW = Handwheel Diameter, ~H = Fully Open Height, C = Thread Depth / Engagement, Rc = Thread Size, ØSW = Socket Weld Diameter, D = Socket Depth.
