Cast Steel Globe Valve (Bolted Bonnet)
Cast Steel Globe Valve (Bolted Bonnet)
FlowBiz is a leading manufacturer of factory-engineered Cast Steel Globe Valves, built with high-quality materials for exceptional durability and long-term industrial use. Designed primarily to regulate flow and pressure, our globe valves also provide a secure, complete shut-off, making them highly effective as block or isolation valves.
Unlike standard gate valves, the FlowBiz Globe Valve is specifically engineered for excellent performance in partially open positions, offering reliable flow regulation without seat damage.
Key Engineering Features
- Excellent Throttling Control: Provides precise regulation for applications requiring positive ON/OFF duty and handles the resistance caused by flow direction changes.
- Rapid Operation: The shorter travel distance of the disc between the open and closed positions allows for frequent, instant, and rapid operation.
- Economical Maintenance: Designed for low maintenance; the valve disc and seat can be replaced quickly on-site with minimal difficulty and expense.
- Robust Sealing: Features a bolted bonnet, outside screw and yoke (OS&Y), graphite packing, and high-integrity Stainless Steel/Graphite gaskets to ensure zero leakage.
Technical Specifications & Operating Data:
FlowBiz Globe Valves strictly adhere to global manufacturing and safety standards.
|
Specification |
Details |
|
Size Range |
2 inches to 12 inches (50mm to 300mm) |
|
Pressure Class |
Class 150 to Class 600 |
|
Max Allowable Pressure |
1500 psi (106 bar) |
|
Max Allowable Temperature |
1500˚F (816˚C) |
|
General Valve Design |
BS 1873 |
|
Pressure/Temperature Rating |
ASME B16.34 |
|
End-to-End Dimensions |
ASME B16.10 |
|
Flange Dimensions |
ASME B16.5 and MSS SP44 |
|
Buttweld Ends Standard |
ASME B16.25 |
|
Testing Standard |
API 598 |
Customizations & Add-Ons:
We provide tailored automation and structural add-ons upon request to meet your specific project requirements:
- Gear Operators for ease of handling.
- Electric Actuators for automated systems.
- Bypass Execution to balance pipeline differential pressure.
- Buttweld ends as per ASME B16.25.
- 100% Radiography testing for critical applications.
Industries We Serve
Our Bolted Bonnet Globe Valves are trusted for managing water, steam, gas, oil, and harsh chemical media across various sectors:
- Refineries & Petrochemicals
- Power Generation Stations
- Process & General Manufacturing
- Oil & Gas Pipelines
India’s Trusted Globe Valve Manufacturer
Based in Ahmedabad and Mumbai, FlowBiz is the preferred partner for premium flow control solutions across the Indian subcontinent.
Regional Supply Excellence: Gujarat & Maharashtra
We provide dedicated logistics and technical support to major industrial hubs:
- Gujarat: Ahmedabad, Vapi, Valsad, Surat, Gandhidham, Kutch, Ankleshwar, Bharuch, Dahej, Sanand, and Navsari.
- Maharashtra: Mumbai, Pune, Nashik, Thane, Aurangabad, Nagpur, Kolhapur, Ambernath, and the Konkan region.
Pan-India Distribution
FlowBiz supports critical infrastructure projects from Tamil Nadu (Chennai, Coimbatore, Salem) to Madhya Pradesh(Indore, Bhopal), ensuring that world-class, BS 1873 standard valves are accessible nationwide.
Why Partner with FlowBiz?
At FlowBiz Exports Pvt. Ltd., an ISO 9001:2015 certified company, we specialize in precision flow regulation. Every Cast Steel Globe Valve is rigorously tested under API 598 standards to ensure it withstands high pressures and harsh industrial environments, giving you ultimate control over your pipeline.
Contact FlowBiz today for high-performance globe valve solutions. At FlowBiz, We Know The Flow.
