3-Way Ball Valve CS Body Flanged End 150 Class (L Port) – Code 1011A
Multi-directional flow routing requires precise, leak-tight divert solutions. Flowbiz Exports Pvt. Ltd. manufactures the 3-Way L-Port Cast Steel Ball Valve (Code: 1011A), designed to efficiently divert or mix process fluids across chemical, oil, and gas, and water handling systems.
What is an L-Port 3-Way Ball Valve?
An L-port ball valve contains a 90-degree hole drilled through the ball core, allowing flow to be directed from a common inlet port to either of two outlet ports. Soft seating across all 3 ports ensures Class VI zero-leakage isolation when switching between process lines.
Technical Specifications (Code: 1011A)
|
Parameter |
Specification Details |
|
Product Code |
1011A |
|
Brand / Manufacturer |
Flowbiz Exports Pvt. Ltd. |
|
Valve Type |
3-Way Ball Valve (L-Port configuration) |
|
Body Material |
Cast Steel (CS) |
|
Size Range |
1 inch to 6 inch (25 mm to 150 mm) |
|
Pressure Rating |
ASA 150 Class |
|
End Connection |
Flanged End 150 Class |
|
Operating Temperature |
-38°C to 200°C |
|
Seat Leakage |
Class VI (Soft Seat - Zero Leakage) |
|
Actuation / Operation |
Manual Hand Lever / Gear Operator / Pneumatic or Electric Actuator |
Key Features & Design Standards
- Blow-Out Proof Stem: Mechanically retained stem design guarantees safety under extreme system line pressures.
- Low Emission Packing: Advanced gland packing reduces fugitive emissions, aligning with strict environmental standards.
- Triple-Port Sealing: Precision-engineered seats behind all 3 ports prevent cross-port leakage during flow diversion.
- ISO 5211 Mounting Pad: Available on request for quick, direct integration of pneumatic or electric actuators.
- Compliance Standards:
- Design & Manufacturing: BS EN ISO 17292 / ASME B16.34
- Flange Drilling: ASME B16.5
- Inspection & Testing: API 598 / ISO 5208
Reliable Supply Chain Across India & Abroad
Flowbiz Exports guarantees rapid delivery and local support through an extensive distribution network across major industrial hubs:
- Gujarat: Key industrial hubs including Ahmedabad (Odhav, Vatva, Naroda, Sanand), Vapi, Bharuch, Dahej, Gandhidham, and Surat (Hazira, Sachin).
- Maharashtra: Major industrial centers such as Mumbai, Pune, Nashik, Nagpur, and Aurangabad.
- International Footprint: Proudly exporting high-pressure multi-port valve solutions to clients across Africa.
